Solar Pumps
One Stop Irrigation Service sells a lot of solar water pumps from different brands like Franklin, Grundfos, and BW Waterboy.
We are after happy customers, and finding the right solar pump is a trade in itself. We can’t stress it enough, please give us an obligation free call, and together can we figure out the best solution for the best price.
Franklin SubDrive Solar Water Pumps
SubDrive Solar Water Pumps are tested and assembled to make sure that when installed, no unexpected errors occur. No electrician is required.
Applications
- Livestock Watering
- Tank Filling
- Wildlife Refuge & Game Farms
- Rural Water Supply for Homesteads
- Irrigation Systems
- Fountains
- Vineyards
- Renewable Energy Projects
- Mining Water Transfer
- Water from Bores, Rivers, Dams & Creeks
Built-in Diagnostics and Protection
The SubDrive Solar QuickPAK products include diagnostic features and built-in protection from potentially harmful conditions.
- Surge
- Short Circuit
- Under Load
- Overheated Controller
- Under Voltage
- Dry Run
- Locked Pump
- Reversed Polarity
- Open Circuit
All-in-One Package
The SubDrive Solar QuickPAK is the System Solution to your solar pumping requirements. Using Franklin quality components, our technical expertise in groundwater pumping, and innovative thinking based on global market inputs, we have developed a rugged, high-output system which tackles the challenges of remote and harsh environments. No other system delivers the features, benefits, and reliability of SubDrive Solar QuickPAK in just one package!
The SubDrive QuickPAK includes:
- Franklin Solar motor
- Franklin Solar pump
- SubDrive Solar controller
- Flow switch with 10m cable
- Variety of flow rates available in 30, 45, 70, 150, and 270 L/min.
- Motor and drive rating available in 1.1 and 2.2 kW
Features
High flow system for faster tank fill and significant water output.
Proven motor and pump technology and reliability.
Robust IP55, NEMA 3 drive enclosure minimises impact of wildlife, insects, dust and weather.
DC & AC power inputs with auto-switching to generator back-up.
Seven segment controller display shows real-time input watts and system status.
Remote telemetry capability through a RS-485 continuous data port.
Max Power Point Tracking for maximising efficiency of input power.
Soft start feature prevents water hammer and increases system life.
Allows use of new solar array or retrofit to existing array. (subject to size and performance check)
Simple installation and no required maintenance.
Build-in diagnostics and protection.
C-tick and UL approved.
Observant compatible for remote access and control.
Please click the button below, if you require a detailed brochure or if you would like us to provide you with a quote.
Grundfos Solar Pumps
Grundfos solar bore pump kits come with high quality German solar panels and Dutch pumps, the panels and pump together offer high efficiency, renewable energy that are available in a wide performance range. With 10 different pumps sizes and a choice of solar panel arrays a suitable solution can be found for your needs.
The Grundfos solar kits are a cost-efficient alternative to irregular, cost-intensive water supply solutions in remote locations(eg. Wind Mills). It provides individual solutions to water problems where conventional water supply systems fail or simply cannot reach.
The complete SQFlex pump range consists of 10 different pump sizes: 4 helical rotor pumps for medium to high heads and low to medium flows, and 6 centrifugal pumps for shallow heads and high flows. It is available in AISI 316 stainless steel for slightly aggressive water. The pump is fitted with a high efficiency motor for DC or AC voltage. This makes pump sizing and selection extremely easy.
Applications
Being designed for continuous as well as intermittent operation, the SQFlex system is especially suitable for water supply applications in remote locations, such as:
- Villages, schools, hospitals, single-family houses, etc.
- Farms — watering of cattle
- Watering applications
- Conservation areas
- Floating pump installations for pumping of water from ponds and lakes.
Features and benefits
- Dry-running protection with automatic restart prevents pump damage to the pump
- Stainless steel pump casing for long service life
- Carbon Ceramic bearings ensure high reliability
- MPPT (Maximum Power Point Tracking) ensures even and high system efficiency regardless of power source
- Two way communication between the control unit and the pump eliminates the need for additional wires
- Wide voltage range 30-300 VDC and 90-240VAC makes installation and sizing especially easy
BW Waterboy Solar Pumps
Features:
- Fully adjustable speed and remote switching timer
- Low water, tank full and remote switching contacts
- Clear cover allows visible inspection of connections and of indicator LED status lights
- MPPT and current booster technology incorporated
- Mounted above ground for longer life and easy access
- Brushless DC motor technology avoids conventional DC brush maintenance
- Modular concept with separate electronics,
Entire pump and motor is stainless steel - CE certified ISO 9001
3HRSS
- 40 meters / 130 feet max lift
- 30 litres / 6.6 gallons per minute max flow
- Voltage range 24-48 Volts, Max 100Voc
- Power range 180 Watts to 500 Watts
- Highly reliable helical rotor technology
- 3 inch / 75mm diameter
- 2 year warranty
4HRSS
- 50 meters / 165 feet max lift
- 52 litres / 11.4 gallons per minute max flow
- Voltage range 48 Volts, Max 100Voc
- Power range 300 Watts or 800 Watts
- Highly reliable helical rotor technology
- 4 inch diameter 100mm
- 2 year warranty
3HRSS-H
- 70 meters / 230 feet max lift
- 36 litres / 7.9 gallons per minute max flow
2160 litres / 475 gallons per hour max flow - Voltage range 24-48 Volts, Max 100Voc
- Power range 360 Watts to 500 Watts
- Highly reliable helical rotor technology
- 3 inch / 75mm diameter
- 2 year warranty
4HRSS-H
- 80 meters / 260 feet max lift
- 55 litres / 12.1 gallons per minute max flow
- Voltage range 72 – 110 Volts, Max 200Voc
- Power range 680 Watts to 1000 Watts
- Highly reliable helical rotor technology
- 4 inch diameter 100mm
- 2 year warranty
4CSS
- 80 meters / 260 feet max lift
- 98 litres / 21.5 gallons per minute max flow
- Voltage range 72 – 110 Volts, Max 200Voc
- Power range 680 Watts to 1500 Watts
- Highly reliable centrifugal technology
- 4 inch diameter 100mm
- 2 year warranty
